ART Tube MP
The ART Tube MP is a microphone preamp with a friendly user interface, beautiful meter, +48V phantom power, variable gain and a phase reverse switching. The Tube MP delivers warmth and fatness to any audio source while maintaining an exceptionally low-noise signal path. The Tube MP Studio V3 offers exceptional sound quality and superior performance to that typically found in "on-board" preamps found in today's low-cost mixers, multi-track recorders and audio cards making it an ideal tone-shaping tool for any application.
The Tube MP Studio V3 uses ART's proven V3 (Variable Valve Voicing) Technology to instantly contour the tone to any source. V3 presets were created and fine-tuned by some of the industry's top studio and live-sound engineers and allow instant access to a multitude of preamp settings designed for guitars (electric and acoustic), keyboards, bass guitars, drums, vocals and more. Additionally, the Tube MP Studio V3 employs OPL (Output Protection Limiting) technology to protect the next component in your signal path from clipping and overloads.
Specifications
- Frequency Response: 5Hz to 50kHz (+0 to -1dB)
- Total Harmonic Distortion: <.01>
- CMMR: > 75dB (typ. @ 1kHz)
- Dynamic Range: <100dB
- Equivalent Input Noise: -129dBu (A weighted, xlr to xlr)
- Maximum Gain: 80dB (xlr to xlr); 74dB (1/4" to xlr)
- Maximum Input Level: +19dBu (xlr); +22dBu (1/4")
- Maximum Output Level: +28dBu (xlr); +22dBu (1/4")
- Phantom Power: +48 volts
- Power Requirements: 110-125 VAC, 16W
- Tube Type: 12AX7A - Dual Triode (Hand Selected)
- Dimensions: 5.0"D x 5.5"W x 2.0" H
- Weight: 1.5 lbs
