The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and multimedia for commercial applications.

Bluetooth 5.0 wireless input and user-intuitive OLED screen with quick-start QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas amplifiers offer the perfect combination of power, performance and flexibility.

The ultimate choice for large-scale 70V/100V distributed audio systems, the 2160BH efficiently powers multiple zones with premium sound clarity and reliable, consistent coverage. Ideal for hotels, conference centers, and multi-room installations, the 2160BH offers high output with advanced features for integrators handling complex, high-demand applications.

Features

• Premium amplification with advanced DSP for optimized performance
• Bluetooth connectivity and RCA connectivity—no wire splicing required
• Intuitive front-panel OLED screen for easy setup and control
• Embedded quick-start QR code in the OLED screen simplifies installation
• Supports high-impedance (70/100V) applications
• Multi-zone flexibility—support for up to two independent zones
• Remote level control with Bose Professional or third-party wall controllers
• Dynamic EQ adjusts bass levels to achieve a fuller sound even at low volumes
• Up to 30 selectable EQ presets ensure Bose Professional signature sound performance and long-term reliability
• Opti-Voice paging feature ensures clear speech intelligibility

Applications

• Retail stores
• Restaurants and bars
• Hospitality venues
• Conference centers
• Schools
• Auxiliary zones

Specifications

Amplification

• Channel Separation (Crosstalk): ≤ -58 dBu below rated power, 1 kHz
• Dynamic Range: 88 dB
• Frequency Response: 20 Hz – 20 kHz (+0/-3 dB) at 1 W, 1 kHz reference
• Rated Power, Symmetrical: 2 x 160 W at 70/100V
• THD+N: ≤ 0.5% at rated power

Audio Inputs

• Adjustment Range: 0 dB to -30 dB (line), 0 dB to +50 dB (page)
• Input Channels: (2) balanced line, (2) unbalanced line, (1) balanced mic/line
• Connectors: (2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock
• Input Impedance: 20 kΩ (line), 2 kΩ (page)
• Input Range: -8 dBu to +22 dBu (line), -58 dBu to +12 dBu (page)
• Maximum Input Level: 22 dBu (line), 12 dBu (page)
• Nominal Input Level: 4 dBu (line), -38 dBu (page)
• Sensitivity: -8 dBu (line), -58 dBV (page)

Audio Outputs

• Channels: (2) loudspeaker, (1) unbalanced line
• Connectors: (2) 2-pin inverted Euroblock, (1) RCA stereo pair
• Nominal Output Level: 2 × 160 W at 70V/100V (loudspeaker), 2 dBu (auxiliary)

Indicators & Controls

• Controls, Front Panel: Power on/off switch, input select switch (A/Bluetooth/B), rotary encoder
• Controls, Rear Panel: Amplifier mode DIP switches, input gain knobs (A, B, page), page threshold knob, mute connector, ControlCenter ports

Integrated DSP

• A/D and D/A Converters: 48 kHz / 24-bit
• Audio Latency: 10.4 ms (any input to speaker output or aux output)
• Presets: 70 Hz high-pass filter, 80 Hz high-pass filter, AMU105, AMU108, DesignMax (all models), EdgeMax (all models), FreeSpace FS (all models), subwoofer
• Processing Functions: Loudspeaker EQ, Opti-Voice paging, Dynamic EQ

Electrical

• Mains Connector: IEC C14 inlet
• Mains Voltage: 100–240 VAC (±10%), 50/60 Hz
• Protections: High temperature, output short circuit, excessively low/high AC line voltage
• AC Power Consumption: 13.6 W standby, 500 W maximum

Physical

• Cooling System: Fan system, left-to-right airflow
• Product Dimensions (H×W×D): 44 mm × 483 mm × 324 mm (1.7 in × 19.0 in × 12.8 in)
• Net Weight: 4.4 kg (9.7 lb)
• Shipping Weight: 5.8 kg (12.8 lb)
