Schertler GIULIA-X - 2-Channel 70W Acoustic Amplifier (Wood Finish)
Schertler GIULIA-X - 2-Channel 70W Acoustic Amplifier (Wood Finish)
The Schertler GIULIA X represents the state of the art in Swiss amplifier design, reflecting all the needs of the user. Offering a significantly improved power amp and speaker section, together with a crossover filter network, limiter and gain, this amp provides 70W (108dB SPL) of bi-amplified analog power. GIULIA X has a coaxial speaker system with a 1” dome tweeter and 5.5” woofer. It is designed with an optimized 2-way bass reflex construction.
GIULIA X is ideal for those seeking no-compromise acoustic instrument amplification, while keeping things small and simple. Perfect for practice and home studio use, it is also recommended as a high-quality preamp in venues, connected to Front Of House via the DI Out. The two inputs can accept one instrument and a vocal microphone.
GIULIA X is available in a choice of wood or anthracite finishes.
Schertler GIULIA-X Specifications
- Weight: 7.5 kg
- Dimensions (LxDxH): 27 x 18 x 28 cm
- Frequency Response (@ +/-3dB): 55 to 20 kHz
- Sensitivity (1W/1m) @1 kHz: 92.5 dB
- Power: 70 W Pure analog power
- SPL Max: 108 dB
- Speakers: 1” dome tweeter, coaxial 5.5” woofer
- Box construction: 12 mm birch BB laminated
- System - Format: Bass reflex - Two way - Bi-amp
- Mic In connector: XLR
- Mic In sensitivity: -52 dB
- Mic In impedance: 4.7 kΩ
- Instrument In connector: 1/4" jack unbalanced
- Instrument In sensitivity: -47 dB
- Instrument In impedance: 820 kΩ
- Insert: On master
- Line Out connector: 1/4" jack
- Line out level: 0 dB
- Line Out impedance: 200 Ω
- DI Out connector: XLR
- DI Out level: -15 dBu
- DI Out impedance: 200 Ω
- Phantom Power (nominal): 24 VDC (XLR) / 10 VDC (jack)
- Effect: Spring-type digital reverb
- Preamp: Class-A, no negative feedback, no integrated circuits
