Drawmer MX60-Pro Channel Strip
Drawmer MX60-Pro Channel Strip
The Drawmer MX60-Pro Front End One is a unique mic/line/instrument input channel in a single rack space providing high quality Drawmer processing prior to tape/hard disc recording. The MX60 is also ideally suited to project studio and live sound applications. Functioning as a studio grade mic pre-amp, Program AdaptiveTM gate, de-esser, compressor, limiter, three band EQ and multi band tube saturation stage, the MX60 offers the user more options than competitive units currently available.
Drawing on many years of experience in professional audio, Drawmer have developed a series of lower-cost dynamic signal processors, the MX Pro range. Aimed at those who are determined not to compromise on quality, but have to work to a tighter budget.
By using circuit elements drawn from existing top-of-the-line Drawmer products and by simplifying the control systems where possible, the MX Pro range is no less sophisticated than the brand's other units, despite the price tag. As a result, the inexperienced user gains the benefits of Drawmer quality and performance, combined with lower cost and simplicity of operation.
Drawmer MX60-Pro Features:
- Channel strip for studio and live sound consisting of Mic preamp, Compression, EQ, De-esser, Gate, Limiter and unique "Tubesound™" processor
- Pre-amplifier for mic, line, or instrument.
- Switchable 48V phantom power and phase reverse
- Program-adaptive Gate, VCA compressor, De-esser, and EQ
- Tubesound stage designed to emulate "Tube Saturation" for subtle warming effects
- Three band equaliser providing shelving high and low sections and fully parametric mid-range EQ, which can provide up to 16kHz AIR band
- De-esser circuit: adapts to the Dynamics and level of the incoming material, eliminating the need for a manual Threshold control and creating more natural results
- Limiter on the output stage with a preset threshold (+16dB)
