Bettermaker Mastering Compressor - Analogue Mastering Compressor with Touch Screen

£2,399.00 inc. vat
£1,999.17 ex. vat
SKU SBETMASTCOMP
Please contact us for availability.

Bettermaker Mastering Compressor - Analogue Mastering Compressor with Touch Screen

The Bettermaker Mastering Compressor is a digitally controlled analogue compressor. The Mastering Compressor is a 2U design with a 5" touchscreen, designed to answer the requirements of mastering engineers.

The Bettermaker Mastering Compressor uses an advanced analogue VCA design which can be switched between peak or RMS as well as feedforward or feedback modes. It also boasts three different modes designed to alter the VCA behaviour and recreate the sound of two of the best VCA compressors.

In addition to the different modes, the Mastering Compressor offers a plethora of features, such as dual-mono, stereo and mid/side operations, Dry/Wet mix control, Side-chain HPF, LPF and fully parametric filtering. A Range Setting also offers a gain reduction limit, ensuring that no matter how much higher from the threshold the signal goes, the compression will only be of the amount set by the ratio control.

Like all other Bettermaker units, all parameters of the Mastering Compressor are digitally controlled via the front panel or by the plug-in and automatable.

Features

  • 100% analogue signal path
  • 5” capacitive touchscreen with backlight
  • Advanced analogue VCA compressor with Peak and RMS detection BM, SG and DX modes
  • Stereo, dual-mono, mid/side operation with solo and side-chain preview function
  • Dry/Wet Mix control for parallel compression
  • HPF, LPF and fully configurable parametric side-chain filter
  • Range Setting for limiting the amount of gain reduction
  • Digitally controlled parameters via front-panel or plug-in.
  • Onboard measurement of Peak/RMS levels



Technical specifications

  • Frequency response 10Hz to 22kHz (+/- 0.2 dB)
  • Dynamic range: 106dB (+23dBu, 22kHz BW)
  • S/N ratio: 87dB (A-weighted, +4dBu, 22kHz BW, unity gain)
  • Crosstalk: -83dB @ 1kHz, +18dBu, channel-to-channel
  • CMRR: max 85 dB @ 3 kHz, min 52 dB @ 20Hz, 20 kHz BW
  • THD: 2nd: < 0.06%, 3rd: < 0.01%; 4th: < 0.006%; (+4 dBu, 20-20 kHz, unity gain, THD and CLIP disabled)
  • balanced stereo input (XLR), 23dBu max input level (THD < 0.2%)
  • balanced stereo output (XLR), 23dBu max output level (THD < 0.2% into >2kohm)Input impedance (differential): 48kΩ (for balanced signal)
  • Output Impedance: 50Ω + 50Ω (electronically balanced)
  • 2U enclosure, 230mm deep (Mastering Compressor)
  • 1U enclosure, 230mm deep (Bus Compressor)
  • universal 100 – 240V power supply designed by Bettermaker
  • Maximum power consumption: 25W
  • Shipping weight: 5.5 kg (Mastering Compressor), 5 kg (Bus Compressor)
