Bettermaker PEQ_Core 1U Passive Stereo EQ with Plugin Control

Bettermaker PEQ_Core 1U Passive Stereo EQ with Plugin Control

The Bettermaker PEQ_Core is a compact 1U passive stereo EQ that keeps the audio fully analogue while every control lives in a DAW plugin, giving you classic passive tone with instant recall and automation. It uses the same style of boost-and-cut passive curves as Bettermaker's larger passive EQs, including the extended 20kHz and 28kHz air bands, in a chassis that takes up just one rack space.

With no settings to note down or rebuild, PEQ_Core suits mastering engineers moving quickly between projects, mix engineers who want analogue EQ on buses and stems, and multi-room facilities that need sessions to recall exactly. Its size also makes it practical to run several units side by side for multi-bus hybrid mixing.

Key Features:

• 100% analogue audio path:
  Passive EQ circuitry with all parameters set digitally.
• Plugin control:
  Every parameter is set, automated and recalled from the Bettermaker plugin over USB (Mac and PC).
• Air bands:
  High boost goes up to 20kHz and 28kHz for open, detailed top end.
• Stereo or dual mono:
  Precisely linked stereo operation, or each channel set separately.
• Snapshots:
  Store settings and switch them quickly between songs or sections.
• Band Audition:
  Solo a band to hear exactly what you are adjusting.
• Metering:
  The plugin shows input and output meters.
• 1U chassis:
  Fits easily into busy racks and multi-unit setups.

In the Box:

• Bettermaker PEQ_Core
• Bettermaker PEQ_Core plugin (download from Bettermaker)

Specifications:

• Low boost / cut frequencies: 20, 30, 60, 100Hz
• Low boost / cut range: +15dB / -16dB
• High boost frequencies: 3, 4, 5, 6, 8, 10, 12, 16, 20, 28kHz
• Maximum high boost: +18dB
• High cut frequencies: 5, 10, 20kHz
• Operation: stereo linked or dual mono
• Control: plugin via USB, macOS and Windows
• Audio path: 100% analogue
• Format: 1U rackmount
