Roger Mayer RM58 LM Limiter VINTAGE SERIES - Stereo Rack Unit 2U

Roger Mayer RM58 LM Limiter VINTAGE SERIES - Stereo Rack Unit 2U

The Roger Mayer RM 58 Classic is a hand-built, Class A stereo limiter designed to deliver precise, musical dynamics control while preserving the character and detail of the source. Combining a proprietary FET gain-reduction circuit with transformer-balanced connectivity, it offers a distinctive analogue approach to tracking, mixing and mastering.

The RM 58 Classic features two dynamically matched channels, with flexible attack and release controls and adjustable threshold and output levels. Its carefully designed gain-reduction circuit responds to both positive and negative waveform peaks, allowing dynamics to be controlled naturally while maintaining stereo integrity and a coherent centre image.

With its combination of fast, precise peak control and musical analogue character, the RM 58 Classic is equally at home controlling individual sources during recording or adding definition and cohesion to a stereo bus. Channel linking and bypass controls provide additional flexibility, while the large illuminated VU meter allows gain reduction, input or output levels to be monitored at a glance.

Housed in a robust stainless-steel chassis and fitted with gold-plated XLR connections, the RM 58 Classic is built for demanding professional studio environments. As with Roger Mayer’s wider range of analogue equipment, it combines a distinctive circuit design with meticulous hand-built construction.

Key Features

• Hand-built Class A stereo limiter
• Proprietary FET gain-reduction circuit
• Two dynamically matched channels
• Transformer-balanced inputs and outputs
• 10-position attack and release controls
• Continuous or 21-position stepped threshold and output controls
• Large illuminated VU meter for gain reduction, input or output monitoring
• Channel link and bypass switches with LED indication
• Gold-plated XLR connectors
• Robust stainless-steel construction
• Hand-built in the United Kingdom
• Universal power supply included

Technical Specifications

• Input sensitivity: -16dBu to +30dBu
• Nominal input level: +4dBu balanced
• Input impedance: 10kΩ
• Nominal output level: +4dBu balanced
• Output impedance: 100Ω balanced
• Recommended load impedance: 10kΩ or greater
• Signal-to-noise ratio: 95dB
• Headroom: Up to +35dBu maximum input level
• Frequency response: Below 10Hz to above 100kHz
• Format: Standard 3U rackmount
• Weight: 5kg
• Power: +48V DC regulated, universal AC/DC adaptor supplied
