Zoom H6studio - Handheld Recorder

Zoom H6studio

The Zoom H6studio puts studio-grade sound in your hands. With 6 audio tracks, large-diaphragm XY mics, 32-bit float recording, and F-Series preamps, you can capture inspiration wherever it strikes.

Choose between 32-bit float for clip-free recording or use the gain knobs in 16/24-bit for more traditional control. A dedicated format switch lets the H6studio adapt to your workflow quickly.

The H6studio includes four locking XLR/TRS inputs with +48V phantom power and +4dBu line-level support. It also has a stereo mini jack with plug-in power.

The H6studio’s 19.4mm XY microphones capture a rich, flat-response with 123 dB of dynamic range and can withstand 140 dB SPL, enough to record a jet engine.

The H6studio’s preamps deliver ultra-clean audio (-127 dBu EIN). Combined with dual A/D converters and 32-bit float, they provide 132 dB of dynamic range to capture every nuance.

Onboard Speaker

Use the built-in speaker to preview recordings on the spot.

Headphone Out

Use the loud headphone output to monitor or listen back to your recordings in any environment.

Line Out

Use the 3.5mm stereo LINE OUT to connect directly to a camera, easily syncing your audio and video.

Zoom H6studio Features

• 32-bit float and 16/24-bit formats each have their Advantages
  • 32-bit float prevents clipping but requires post-production
  • 16/24-bit eliminates the need for post-processing but requires gain adjustment to prevent clipping
  • The H6studio offers the best of both worlds with 32-bit float and dedicated gain knobs—no clipping and no need for post-production
  • And with the dedicated format switch, you can adapt your workflow quickly
• The H6studio supports sampling rates from 44.1 to 192 kHz
• Capture up to 8 tracks* at once - 6 individual tracks plus a stereo mix
  • *Up to 8 tracks (6 inputs + 2 stereo mixes) at 96kHZ
  • *Up to 6 tracks (6 inputs) at 192kHZ
• The 19.4mm microphones capture audio with incredible frequency Response and 140 dB max SPL
• Their increased size captures recordings with unmatched depth and clarity
• The H6STUDIO features Zooms F-series preamps, giving your audio unmatched clarity (-127 dBu EIN)
• With dual AD converters and 32-bit float, it delivers an impressive 132dB dynamic range
• The H6studio features “advanced look-ahead” limiters which anticipate potential overloads and prevent distortion before it reaches your track
